Features
| Body | Rugged, single die cast, ergonomic design, touch point treated |
|---|---|
| Optical system | Achromatic optical system, colour corrected, anti-fungal, anti-bacterial coated (multi-layered hard coated) |
| Illumination | Halogen or LED with Battery backup, illumination mirror |
| Viewing Head | Monocular, Binocular & Trinocular Head |
| Nosepiece | Quadruple/Quintuple with multiple ball-bearing, rubber/metal grip & click stop |
| Eyepiece | Extra wide field with diopter adjustment |
| Objectives | DIN Semi Plan/plan finite/infinite achromatic |
| Mechanical Stage | Right/left hand control, hard coated surface, double layer, single/double slide holder,low position coaxial movement |
| Condenser | Abbe with iris diaphragm & filter slot brightfiled, darkfiled, phase. |
| Focusing | Coaxial (low position), both side, coarse & fine with tension control & upper limit stopper |
| Certification | EU CE, ISI, ISO, TUV |
Specifications
| Part name | Part Code | Description |
|---|---|---|
| Body | RX4MB | Rugged, robust, single aluminium die cast, ergonomic design, hand rest for comfortable prolonged use. metalic parts with antirust, antibacterial, corrosion-proof & stain-proof coating, acid resistant texture paint, touch point treated, intensity controller & on/off switch, inbuilt light source, on lens filter holder, rubber feet. |
| Optical system | RX4OS | Achromatic optical system, colour corrected, anti-fungal, anti-bacterial coated (multi-layered hard coated), Anti-reflected Coated, lead free optical glass, colour coded objectives |
| Koheler Illumination | RX4H20 | Built-in halogen 6V – 20W (life 2000 hrs.) for uniform illumination |
| Viewing Head | RX4BSL | Binocular inclined at 45°, sliding head, rotatable through 360°, IPD – from 48-76, diopter adjustment on one or both eyepiece |
| Nosepiece | RX4-4N | Parcentered & parfocal, outward tilted, precise quadruple revolving on multiple ball bearing, with postive click stop |
| Eyepiece | RX4EP1018 | Paired, WF 10X, FOV-18mm, multilayered coated, high quality, good contrast, abresion free, aplantic, Anti-fungal & anti-mould treated, precentered, lockable,(single eyepiece in case of monocular head) with rubber gaurd, diaptore adjustment on eyepiece. |
| Mechanical Stage | RX4MS | Rectangular right/left hand low drive control, hard coating, steel single/double slide holder, stage size 135×140mm, X-Y movement 75-50mm(graduated with verier) on stainless steel ball |
| Objectives | RX4AC04 | 4X, N.A. 0.10, W.D. 30mm, DIN/JIS achromatic, parfocal & precentered, unbreakable container for storage |
| RX4AC10 | 10X, N.A. 0.25, W.D. 6.1mm, DIN/JIS achromatic, parfocal & precentered, unbreakable container for storage | |
| RX4AC40 | 40X, N.A. 0.65, W.D. 0.65mm, DIN/JIS achromatic, spring loaded, parfocal & precentered, unbreakable container for storage | |
| RX4AC100 | 100X, N.A. 1.25, W.D. 0.18, DIN/JIS achromatic, parfocal & precentered, oil immered, spring loaded, unbreakable container for storage | |
| Focusing | RXF25 | Co-axial, focusing knob, tension control, upper limit stopper, 25mm stroke high sensitivity focus drive with 0.25 mm per revoluation, fine adjustment 2.5µm/Div. |
| Condenser | RABC | Sub stage Abbe N.A. 1.25 for BF, aspheric lens, separate movement from focusing (rack & pinion) with adjustable iris diaphragm, built-in base illumination, filter holder, slot for phase/Dark field slider |
| Power supply | RSMPS620 | SMPS based, wide voltage range, 90V-240V, 50/60Hz |
| Standard accessories | RCC | Cleaning cloth |
| RVC | Vinyl cover | |
| RIO | Immersion oil (10ml) Lens Cleaning Solution | |
| RA3K | Allen key | |
| RF5A | Fuses – 2 no’s | |
| MANUAL | Instruction manual | |
| WARRANTY | Warranty card | |
| RBF | Blue Filter (frosted & Plain) 32mm diameter | |
| RPC | Power Cord (country Specific) | |
| Lamp (LED), Mirror Unit (Plano Concave) with miror holder attachment |
